Controlled check valve, CBF, VBS-38-SP-A, 3/8"
- Controlled check valve, single, manufactured by CBF, type VBS-38-SP-A with internal thread G 3/8".
Controlled check valve, single, manufactured by CBF, type VBS-38-SP-A with internal thread G 3/8".
BASIC DATA
| Maximum flow rate |
35 l/min |
| Connections V1, V2 |
femalethread G 3/8" (according to BSPP¹) |
| Connections C1, C2 |
g 3/8" female thread (acc. to BSPP¹) |
| Maximum working pressure |
350 bar |
| Own weight | |
| Country of origin |
Italy |
| Manufacturer's website |
www.cbfhydraulic.com |
- British Standard Pipe Parallel - British StandardPipe Parallel , inchcylindrical thread , one of the Whitworthpipe threads(BSP) denoted by the letter G.
Note: The technical and operational parameters of the product given above are for informational purposes only. The owner and administrator of the online store hydromech.eu are not responsible for their compliance with the parameters of the product supplied by the manufacturer.
