Hydraulic Directional Valve Presko dedicated to forestry trailers, among others. 8 sections, including two 12V electric sections. Flow rate up to 90l/min.

✅ Hydraulic Directional Valve has three types of control:

  • Two 4 position joysticks - up/down/right/left positions + neutral position.
  • Two 12V sections - operated by buttons on the joysticks. Buttons allow extending and retracting cylinder.
  • Two levers on spring - each lever operates one section each. Each lever returns to the neutral position as soon as you take your hand away from it.

- Number of sections: 8

- Maximum flow rate: 90l/min

- Maximum operating pressure: 250 bar

- Safety valve set at: 180 bar

- Individual pressure control on sections

✅Most important features:

  • Hydraulic Directional Valvee PRESKO are used by many Polish and foreign manufacturers of agricultural, construction and industrial equipment
  • High-quality materials used in production guarantee long and trouble-free operation
  • Robust and compact sectional design
  • Easy to install
  • Has the possibility of expansion
  • Equipped with a safety valve
  • Hydraulic Directional Valve ideal for forestry trailers
  • has additional valves to regulate pressure on individual sections.

✅ Connection:

  1. Pump supply P: 1/2'' BSP female thread
  2. Return to tank T: 3/4'' BSP female thread
  3. Outlet to sections: internal thread BSP 1/2''
