PRESKO gear pump with PTO multiplier - set 26 cm3
- PRESKO gear pump 2 group with PTO male multiplier - set 26 cm3
Hydraulic gear pump, group 2, male PTO multiplier 1:3.8
The set includes:
 |
PRESKO gear pump
|
 |
PRESKO PTO multiplier
|
Capacity in liters per minute
- 220 rpm on the PTO shaft = 21,7 l/min.
- 320 rpm on the PTO shaft = 31,6 l/min.
- 430 rpm on the PTO shaft = 42,4 l/min.
- 540 rpm on the PTO shaft = 53,3 l/min.
Dimensions
- 1 - 123,5 mm
- 2 - 59,5 mm
- 3 - 1/2'' - inlet
- 4 - 3/4'' - outlet
TECHNICAL DRAWING
Note: The technical and operational parameters of the product are for customer’s information. The owner and administrator of the hydromech.eu online store are not responsible for their compliance with the parameters of the product supplied by the manufacturer. The source data is included in the manufacturer's brochure.
To download
Brand
Entity responsible for this product in the EU
HeweaSp. z o.o.More
ProducerHeweaSp. z o.o.Address:
Przemysłowa 1Postal code: 55-095City: MirkówCountry: PolandPhone number: 71 345 60 00E-mail: info@hewea.com
Responsible entityHEWEA SPÓŁKA Z OGRANICZONĄ ODPOWIEDZIALNOŚCIĄAddress:
Przemysłowa 1Postal code: 55-095City: BykówCountry: Poland
Symbol
ZYP2FC026B03 + 33-60001-6
Producer code
ZYP2FC026B03 + 33-60001-6
