Grab Rozzi R74/500
- Hydraulic attachments for loose materials: - earth, sand, gravel - RDF - silt - cereals, fertilizers - coal - industrial, agricultural wastes
Grab for loose materials R74/500
Graband for bulk materials is hydraulic equipment that is designed for two main tasks - digging, with vertical cylindermi and a tooth profile for high penetration, and loading, with horizontal cylindermi to reduce overall height and a geometric tooth design for maximum filling.
Application:
The loading version is used for handling materials such as:
- earth
- sand
- gravel
- RDF
- silt
- cereals
- coal
- fertilizers
- industrial waste
- agricultural waste
Construction:
The steel structure and cylinderand are made of high quality steel, and the blades, which are subject to abrasion, are made of HB400/500 wear-resistant steel.
Technical specifications:
- Model: R74/500
- Capacity: 500dm3
- Weight: 370 kg
- Working pressure: 300 bar
- Oil demand: 70 l/min
- Clamping force: 2470 kg
Technical drawing:
- A: 1400 mm
- B: 1460 mm
- C: 1300 mm
- D: 990 mm
- E: 650 mm
- F: 135 mm
- L: 1000 mm
Note: The technical and operational parameters of the product given above are for information purposes only. The owner and administrator of the online store hydromech.eu are not responsible for their compliance with the parameters of the product supplied by the manufacturer. The source data is provided in the manufacturer's brochure, which can be downloaded from the "Download" tab (below).
